Horizontal boring & milling center
PAMA 5000/160 · Italy · 2022
X 5000 · Y 3200 · Z 2500 mm · Table 50 t
- Home
- Equipment
Production Equipment
The size, weight and accuracy of the parts we make are set by our machines. This page lists every main machine across our machining, fabrication, heat-treatment, metrology and laboratory areas, with model, working range and capacity.
85Machines listed
25+Imported CNC centers
50 tMax. table load
5,000 mmCMM X-axis
Area 01 · 9 machines
Horizontal Boring & Machining Centers
Heavy housings, frames and valve bodies are machined on four sides in one clamping, keeping bores coaxial and faces square.
Horizontal boring & milling center
PAMA 3800/160 · Italy · 2020
X 5000 · Y 2500 · Z 2700 mm · Table 25 t
Horizontal boring center
Huiteng TK6916 · 2024
X 4000 · Y 3000 · Z 1700 mm · Table 50 t
Horizontal machining center
HBM-5T · Taiwan · 2019
X 4500 · Y 2600 · Z 2000 mm · Table 15 t
Horizontal machining center
DOOSAN HM8000
800 mm pallet class · Pallet changer
Horizontal machining center
NIIGATA HN100D
1000 mm pallet class · Pallet changer
Horizontal machining center
DOOSAN NHP6350
630 mm pallet class · Pallet changer
CNC milling centre
6 m class
6,000 mm travel class · Long shafts and rolls
Area 02 · 10 machines
Gantry & 5-Axis Machining
Long beds, bases and complex carriers are machined on gantry and 5-axis gantry centers, often in a single setup.
Gantry machining center
Kao Ming KMC-4000SV-H · Taiwan · 2020
X 4230 · Y 2650 · Z 775 mm · Table 15 t
Gantry machining center
HARTFORD HEP-3150
3,000 mm class
Gantry machining center
VTEC SF-4150
4,000 mm class
5-axis gantry machining center
UB432Z2
4,000 mm class · 5-axis simultaneous
5-axis gantry machining center
HMF4030
4,000 × 3,000 mm class · 5-axis simultaneous
CNC gantry milling machine
Heavy gantry mill
Large plates and bases
Area 03 · 12 machines
Turning & Turn-Milling
Rings, discs, hubs and shafts are turned on vertical turn-mill centers to the Ø3,200 mm class and on heavy-duty horizontal lathes.
CNC vertical turn-mill center
VTL3200ATC+C · 2025
Table Ø3000 · height 2000 mm · 15 t · C-axis 0.001°
CNC vertical turn-mill center
VTL2500ATC+C · 2020
Table Ø3000 · height 2000 mm · 15 t · C-axis 0.001°
High-speed CNC vertical lathe
YOU JI VTL2500ATC-I · Taiwan · 2021
Table Ø2800 · Z 900 mm · 15 t
CNC vertical lathe
VT2500 + ATC
Ø2,500 mm class · ATC
CNC vertical lathe
YOU JI YV-1600ATC
Ø1,600 mm class · ATC
CNC vertical lathe
YOU JI YV-1000ATC
Ø1,000 mm class · ATC
CNC vertical lathes
Heavy casting line
Ø1.6 m × 3 · Ø2.5 m × 2
Heavy-duty CNC lathe
DOOSAN PUMA 700L
Large-swing shafts
Heavy-duty CNC lathe
DOOSAN PUMA 800LB
Large-bore shafts
CNC lathe
DOOSAN PUMA 280L
Medium shafts
Heavy horizontal lathe
Roll and shaft turning
Long heavy shafts
Area 04 · 4 machines
Vertical Machining & Drilling
Precision small and medium parts, fixtures and covers.
Vertical machining center
DOOSAN Mynx 9500/50
Large table VMC · BT50 spindle
Vertical machining center
DOOSAN Mynx 750/50
Medium table VMC · BT50 spindle
Vertical machining center
VMC-168G
1,600 mm X travel
Area 05 · 7 machines
Grinding & Gear Cutting
Finish grinding after heat treatment, plus hobbing, shaping and grinding of gears, splines and racks.
High-precision cylindrical grinder
MC1363 × 4000H
Ø630 × 4,000 mm
High-precision cylindrical grinder
MQ1350B × 3000
Ø500 × 3,000 mm
High-precision cylindrical grinder
MGA1432 × 1500
Ø320 × 1,500 mm
Cylindrical grinding of rolls
Heavy roll grinding
Large rolls and shafts
Gear hobbing machine
Large gear rims
Coarse module
Gear shaping machine
Internal gears and splines
Gear grinding machine
Hardened gear teeth
Area 06 · 9 machines
Cutting, Forming & Welding
Laser cutting, forming and robotic welding prepare weldments for stress relief and machining.
Fiber laser cutting machine
1400 × 3200 class · 20,000 W
Plate cutting · 20 kW
Laser pipe cutting machine
9200 × 6500 class · 12,000 W
Tube and profile · 12 kW
CNC press brake
400T3200
3,200 mm bending length · 400 t
Robot welding system
φ3650-6T · 10-axis · 360° rotating
Positioner Ø3,650 mm · 6 t
Submerged arc welder
MZ-1250
Thick-section joints · 1,250 A
Gas-shielded pulse inverter welder
EWM Phoenix 551 Puls
MIG/MAG · 550 A
Flexible welding fixtures
Modular 3D tables
Weldment fixturing
Vibration stress relief equipment
VSR system
Post-weld stress relief
Area 07 · 10 machines
Heat Treatment, Coating & Repair
Ten furnaces, induction hardening, quench lines and an automatic coating room finish parts in-house.
Heat-treatment furnaces
Normalize · Q&T · anneal · solution
Large parts · 10 furnaces
Forklift quenching line
Water / polymer quench
Fast transfer · ≤ 30 s to quench
Induction hardening machine
Medium frequency
Shafts, gears, rollers · Depth to 12 mm
Vacuum furnace
Clean heat treatment
Pit furnaces
Long shafts, carburizing
Trolley tempering furnace
RT3-400-6
Tempering, stress relief
Forced air-cooling pit
Accelerated cooling
Fully automatic surface coating room
Primer and topcoat
Spray painting room
Industrial paint systems
Laser cladding system
MobiMFO 35-600
Shaft and flange repair
Area 08 · 11 machines
Metrology & NDT
Large parts are measured on a 5,000 mm gantry CMM or by laser tracker; NDT verifies forgings, castings and welds.
Gantry coordinate measuring machine
Hexagon · Sweden · 2020
5000 × 4000 × 2500 mm
Bridge coordinate measuring machine
PC-DMIS software
1500 × 3000 × 1000 mm
3D laser tracker
FARO Vantage
Large weldments, in situ
3D scanner
Surface comparison to CAD
Castings, weldments
Fluorescent magnetic particle detector
Bench MT
Shafts, gears
Ultrasonic flaw detector
Digital UT
Forgings, castings, welds
Dynamic balancing machine
Rotors, bowls, impellers
ISO 1940 grades
Air-tightness tester
Leak testing
Housings, pressure parts
Surface roughness tester
Ra / Rz
Magnetic coating thickness gauge
Paint and plating
Standard gauges
Micrometers, calipers, height gauges
Area 09 · 13 machines
Materials Laboratory
Chemical, mechanical and metallographic testing confirms every heat before machining and qualifies critical parts.
Spark OES spectrometer
NCS SparkCCD 7000
Steels, stainless, non-ferrous
Direct-reading spectrometer
Optical emission
Chemical composition
ICP-AES spectrometer
Thermo
Trace and alloying elements
C/S analyzer & O/N/H determinator
LECO
C, S, O, N, H content
Tensile testing machine
Universal tester
Tensile, yield, elongation
Mechanical testing machine
Servo-hydraulic
Tensile, compression, bend
High-temperature tensile tester
CRIMS
Elevated-temperature tensile
High-temperature creep machines
CRIMS
Creep and stress rupture
Low-temperature impact tester
Charpy pendulum
Impact toughness
Hardness tester
Rockwell / Brinell
Hardness
Friction-abrasion testing machine
Wear testing
Coatings, hardened surfaces
Metallographic microscope
ZEISS inverted
Microstructure, grain size
Metallurgical microscope
With image analysis
Case depth, inclusions
Complete equipment list
Every machine, one table
Model, working range, capacity, accuracy and quantity for each main machine. Scroll sideways on small screens.
| Equipment | Model / origin | Working range | Capacity | Accuracy | Qty |
|---|---|---|---|---|---|
| Horizontal Boring & Machining Centers | |||||
| Horizontal boring & milling center | PAMA 5000/160 · Italy · 2022 | X 5000 · Y 3200 · Z 2500 mm | Table 50 t | 0.01 mm | 1 |
| Horizontal boring & milling center | PAMA 3800/160 · Italy · 2020 | X 5000 · Y 2500 · Z 2700 mm | Table 25 t | 0.01 mm | 1 |
| Horizontal boring center | Huiteng TK6916 · 2024 | X 4000 · Y 3000 · Z 1700 mm | Table 50 t | 0.01 mm | 1 |
| Horizontal machining center | HBM-5T · Taiwan · 2019 | X 4500 · Y 2600 · Z 2000 mm | Table 15 t | 0.008 mm | 1 |
| Horizontal machining center | DOOSAN HM8000 | 800 mm pallet class | Pallet changer | — | 1 |
| Horizontal machining center | NIIGATA HN100D | 1000 mm pallet class | Pallet changer | — | 1 |
| Horizontal machining center | DOOSAN NHP6350 | 630 mm pallet class | Pallet changer | — | 1 |
| CNC milling centre | 6 m class | 6,000 mm travel class | Long shafts and rolls | — | 1 |
| Boring machines | Heavy casting machining line | Large castings | — | — | 5 |
| Gantry & 5-Axis Machining | |||||
| Gantry machining center | Kao Ming KMC-4000SV-H · Taiwan · 2020 | X 4230 · Y 2650 · Z 775 mm | Table 15 t | 0.01 mm | 1 |
| Gantry machining center | HARTFORD HEP-3150 | 3,000 mm class | — | — | 1 |
| Gantry machining center | VTEC SF-4150 | 4,000 mm class | — | — | 1 |
| 5-axis gantry machining center | UB432Z2 | 4,000 mm class | 5-axis simultaneous | — | 1 |
| 5-axis gantry machining center | HMF4030 | 4,000 × 3,000 mm class | 5-axis simultaneous | — | 1 |
| CNC gantry milling machine | Heavy gantry mill | Large plates and bases | — | — | 1 |
| Gantry machining center | LM-3022 · Taiwan · 2020 | 3,000 mm class | — | 0.01 mm | 1 |
| Gantry machining center | GMFA3262 · Shanghai · 2022 | 3,200 mm class | — | 0.01 mm | 1 |
| CNC planomiller | Heavy casting line | — | — | — | 1 |
| Planer-type milling machine | 4 m table | 4,000 mm | — | — | 2 |
| Turning & Turn-Milling | |||||
| CNC vertical turn-mill center | VTL3200ATC+C · 2025 | Table Ø3000 · height 2000 mm | 15 t · C-axis 0.001° | 0.01 mm | 1 |
| CNC vertical turn-mill center | VTL2500ATC+C · 2020 | Table Ø3000 · height 2000 mm | 15 t · C-axis 0.001° | 0.01 mm | 1 |
| High-speed CNC vertical lathe | YOU JI VTL2500ATC-I · Taiwan · 2021 | Table Ø2800 · Z 900 mm | 15 t | 0.01 mm | 1 |
| CNC vertical lathe | VT2500 + ATC | Ø2,500 mm class | ATC | — | 1 |
| CNC vertical lathe | YOU JI YV-1600ATC | Ø1,600 mm class | ATC | — | 1 |
| CNC vertical lathe | YOU JI YV-1000ATC | Ø1,000 mm class | ATC | — | 1 |
| CNC vertical lathes | Heavy casting line | Ø1.6 m × 3 · Ø2.5 m × 2 | — | — | 5 |
| Heavy-duty CNC lathe | DOOSAN PUMA 700L | Large-swing shafts | — | — | 1 |
| Heavy-duty CNC lathe | DOOSAN PUMA 800LB | Large-bore shafts | — | — | 1 |
| CNC lathe | DOOSAN PUMA 280L | Medium shafts | — | — | 1 |
| Heavy horizontal lathe | Roll and shaft turning | Long heavy shafts | — | — | 1 |
| Turning-milling combination center | Heavy casting line | — | — | — | 2 |
| Vertical Machining & Drilling | |||||
| Vertical machining center | DOOSAN Mynx 9500/50 | Large table VMC | BT50 spindle | — | 1 |
| Vertical machining center | DOOSAN Mynx 750/50 | Medium table VMC | BT50 spindle | — | 1 |
| Vertical machining center | VMC-168G | 1,600 mm X travel | — | — | 1 |
| Radial drilling machine | Heavy casting line | — | — | — | 1 |
| Grinding & Gear Cutting | |||||
| High-precision cylindrical grinder | MC1363 × 4000H | Ø630 × 4,000 mm | — | IT5–IT6 | 1 |
| High-precision cylindrical grinder | MQ1350B × 3000 | Ø500 × 3,000 mm | — | IT5–IT6 | 1 |
| High-precision cylindrical grinder | MGA1432 × 1500 | Ø320 × 1,500 mm | — | IT5–IT6 | 1 |
| Cylindrical grinding of rolls | Heavy roll grinding | Large rolls and shafts | — | — | — |
| Gear hobbing machine | Large gear rims | Coarse module | — | — | — |
| Gear shaping machine | Internal gears and splines | — | — | — | — |
| Gear grinding machine | Hardened gear teeth | — | — | — | — |
| Cutting, Forming & Welding | |||||
| Fiber laser cutting machine | 1400 × 3200 class · 20,000 W | Plate cutting | 20 kW | — | 1 |
| Laser pipe cutting machine | 9200 × 6500 class · 12,000 W | Tube and profile | 12 kW | — | 1 |
| CNC press brake | 400T3200 | 3,200 mm bending length | 400 t | — | 1 |
| Robot welding system | φ3650-6T · 10-axis · 360° rotating | Positioner Ø3,650 mm | 6 t | — | 1 |
| Submerged arc welder | MZ-1250 | Thick-section joints | 1,250 A | — | — |
| Gas-shielded pulse inverter welder | EWM Phoenix 551 Puls | MIG/MAG | 550 A | — | — |
| Flexible welding fixtures | Modular 3D tables | Weldment fixturing | — | — | — |
| Vibration stress relief equipment | VSR system | Post-weld stress relief | — | — | 1 |
| Argon arc (TIG) welder | VRTP-400 | Root passes, stainless | 400 A | — | — |
| Heat Treatment, Coating & Repair | |||||
| Heat-treatment furnaces | Normalize · Q&T · anneal · solution | Large parts | 10 furnaces | — | 10 |
| Forklift quenching line | Water / polymer quench | Fast transfer | ≤ 30 s to quench | — | 1 |
| Induction hardening machine | Medium frequency | Shafts, gears, rollers | Depth to 12 mm | — | 1 |
| Vacuum furnace | Clean heat treatment | — | — | — | 1 |
| Pit furnaces | Long shafts, carburizing | — | — | — | — |
| Trolley tempering furnace | RT3-400-6 | Tempering, stress relief | — | — | 1 |
| Forced air-cooling pit | Accelerated cooling | — | — | — | 1 |
| Fully automatic surface coating room | Primer and topcoat | — | — | — | 1 |
| Spray painting room | Industrial paint systems | — | — | — | 1 |
| Laser cladding system | MobiMFO 35-600 | Shaft and flange repair | — | — | 1 |
| Metrology & NDT | |||||
| Gantry coordinate measuring machine | Hexagon · Sweden · 2020 | 5000 × 4000 × 2500 mm | — | 0.001 mm | 1 |
| Bridge coordinate measuring machine | PC-DMIS software | 1500 × 3000 × 1000 mm | — | — | 1 |
| 3D laser tracker | FARO Vantage | Large weldments, in situ | — | — | 1 |
| 3D scanner | Surface comparison to CAD | Castings, weldments | — | — | 1 |
| Fluorescent magnetic particle detector | Bench MT | Shafts, gears | — | — | 1 |
| Ultrasonic flaw detector | Digital UT | Forgings, castings, welds | — | — | — |
| Dynamic balancing machine | Rotors, bowls, impellers | ISO 1940 grades | — | — | 1 |
| Air-tightness tester | Leak testing | Housings, pressure parts | — | — | 1 |
| Surface roughness tester | Ra / Rz | — | — | — | — |
| Magnetic coating thickness gauge | Paint and plating | — | — | — | — |
| Standard gauges | Micrometers, calipers, height gauges | — | — | — | — |
| Materials Laboratory | |||||
| Spark OES spectrometer | NCS SparkCCD 7000 | Steels, stainless, non-ferrous | — | — | 1 |
| Direct-reading spectrometer | Optical emission | Chemical composition | — | — | 1 |
| ICP-AES spectrometer | Thermo | Trace and alloying elements | — | — | 1 |
| C/S analyzer & O/N/H determinator | LECO | C, S, O, N, H content | — | — | 2 |
| Tensile testing machine | Universal tester | Tensile, yield, elongation | — | — | 1 |
| Mechanical testing machine | Servo-hydraulic | Tensile, compression, bend | — | — | 1 |
| High-temperature tensile tester | CRIMS | Elevated-temperature tensile | — | — | 1 |
| High-temperature creep machines | CRIMS | Creep and stress rupture | — | — | 3 |
| Low-temperature impact tester | Charpy pendulum | Impact toughness | — | — | 1 |
| Hardness tester | Rockwell / Brinell | Hardness | — | — | — |
| Friction-abrasion testing machine | Wear testing | Coatings, hardened surfaces | — | — | 1 |
| Metallographic microscope | ZEISS inverted | Microstructure, grain size | — | — | 1 |
| Metallurgical microscope | With image analysis | Case depth, inclusions | — | — | 1 |
Inside our workshops
From heavy machining to finishing
Machining, fabrication, heat treatment, inspection and coating each have dedicated halls with overhead cranes sized for multi-tonne parts, so heavy components move between operations without leaving the site.
Equipment FAQ
Questions about our machines
Not sure your part fits? Send the drawing and we will confirm the machine and route.
Check my partWhat is the largest part Songyan Machinery can machine?
Our horizontal boring and milling centers accept workpieces up to 50 t with travels of X 5,000 × Y 3,200 × Z 2,500 mm. Vertical turn-mill centers turn parts in the Ø3,200 mm class up to 2,000 mm high, and machined or welded parts up to 30,000 kg per piece are produced regularly.
How large is your coordinate measuring machine?
Our gantry CMM has a measuring volume of 5,000 × 4,000 × 2,500 mm with 0.001 mm resolution. A bridge CMM of 3,000 × 1,500 × 1,000 mm handles medium parts, and a 3D laser tracker measures large weldments on the shop floor.
What welding equipment do you use?
A 10-axis robotic welding system with a 360° positioner of Ø3,650 mm and 6 t capacity, submerged arc welders rated at 1,250 A, TIG welders at 400 A and pulsed MIG/MAG inverters at 550 A, together with modular welding fixtures.
What laser cutting capacity do you have?
A 20 kW large-format fiber laser for plate and a 12 kW fiber laser for tube and profiles. Heavy plate beyond laser range is cut by plasma or oxy-fuel.
Is the machining workshop temperature-controlled?
Yes. Our precision machining line operates in a 10,000 m² temperature-controlled workshop, which keeps thermal growth of machines and workpieces stable when holding tight tolerances on large parts.
Request a quote
Send your drawings. Get a price and lead time.
Email sales@symachiningparts.com or message us on WhatsApp at +86 189 1530 7612. All drawings are treated as confidential.
